BOSS 6/12k Proportioner- 3 Phase

 Boss 16/12K Single Phase Proportioner is also available

Features

• Dual heating blocks for the ISO and Resin provides extra heating elements for colder climates
• Simple 240V single-phase system. The electrical system is all breaker and relay design, for easy repairs if needed.
• Heating elements are much larger than those in competitive machines, capable of heating more material faster than other proportioners
• Designed to spray polyurethane or polyurea – Foam, bed liners, sealants, slab jacking, etc.
• 3,000 psi maximum working pressure
• Air-driven machine with 6” motor
• Higher pressure output than 5” series
• Powerful and larger heating elements for more material to reach desired Delta-T
• Easily attainable components to minimize downtime
• Easy to power on and off
• Digital heating controls
• Hose heat transformer for up to 400 feet of hose

Technical Data

• Preheat 12,000 watts
• 195 degrees maximum fluid temperature
• 32 lb/min. maximum output
• .0500 gal/cycle output each cycle (A & B pumps)
• Fluid inlet ¾” npt with ½” npt outlet
• Component A (ISO) #6 (3/8”) JIC with #5 (5/16”) JIC adapter
• Component B (Resin) #6 (3/8”) JIC with #6 (3/8”) JIC adapter
• Fluid circulation ¼” with thermoplastic tubing (3,000 psi)
• Parts contacting fluid: stainless steel, zinc plated, carbon steel, aluminum, chrome, brass, PTFE, Viton O-rings
• Weight – 301 lbs.
• Dimensions – D: 24” x W: 28” x H: 52”
• Air requirements – 17 cfm @ 150 psi; requires at least 26-30 cfm @ 100 psi, which is easily acquired with a 18 hp gas air compressor or 10 hp electric air compressor
